Heatsink Spring Mount Rivet
Description
The Sucatec Heatsink Spring Mount Rivet is a two-part assembly designed to secure heatsinks to PCB boards and aid heat dissipation. Constructed from durable Nylon 66 and spring steel, this component provides excellent mechanical retention and temperature resistance for reliable thermal performance. Ideal for electronics assembly where efficient and repeatable mounting of heatsinks is required.
Features
- Material: Nylon 66 and Spring Steel
- Temperature Range: -30°C to +85°C
- High mechanical strength and good flexibility
- Facilitates consistent heatsink pressure for optimal thermal contact
- Push-fit design for fast and clean assembly
- RoHS compliant
Applications
Used for mounting heatsinks onto PCBs and electronic components in applications such as computer boards, power modules, and other heat-sensitive assemblies. Ensures stable attachment and enhanced heat dissipation performance.
Part Numbers
| Part Number | Description |
|---|---|
| SU-HSR-2.6B | Heatsink Spring Mount Rivet – 2.6 mm |
| SU-HSR-3.1B | Heatsink Spring Mount Rivet – 3.1 mm |
| SU-HSR-3.6B | Heatsink Spring Mount Rivet – 3.6 mm |
| SU-HSR-5.8B | Heatsink Spring Mount Rivet – 5.8 mm |
| SU-HSR-6.6B | Heatsink Spring Mount Rivet – 6.6 mm |
| SU-HSR-8.7B | Heatsink Spring Mount Rivet – 8.7 mm |
| SU-HSR-13B | Heatsink Spring Mount Rivet – 13 mm |
| SU-HSR-13.6B | Heatsink Spring Mount Rivet – 13.6 mm |
| SU-HSR-15.6B | Heatsink Spring Mount Rivet – 15.6 mm |
| SU-HSR-17.8B | Heatsink Spring Mount Rivet – 17.8 mm |
| SU-HSR-24B | Heatsink Spring Mount Rivet – 24 mm |
| SU-DG-21B | Heatsink Spring Mount Rivet – 21 mm (Deep Grip Type) |
| Document No.: DS-HSR-2025 | Revision: 01 | Date of Issue: 5 November 2025 |
