TDS – Nylon Hex Nuts

Nylon Hex Nuts

Description

Sucatec’s nylon hex nuts are lightweight, non-conductive fasteners designed for secure and reliable fastening in electrical, electronic, and cleanroom applications. Manufactured from high-grade Nylon 66, these nuts offer excellent mechanical strength, wear resistance, and chemical stability. Their self-locking shoulder design provides a consistent grip, ensuring resistance to loosening under vibration or torque. Ideal for use where metal contact is undesirable or weight reduction is critical, they provide a durable and corrosion-free fastening solution for diverse assembly needs.

Key Features

Material: Nylon 66
Flame Retardancy: UL94 V2
Temperature Range: −35°C to +85°C
RoHS compliant and halogen-free
Excellent insulation and chemical resistance
Available in black or natural (white) finish
Custom sizes available upon request

Dimensional Reference (mm)

Size	A	B	C
M2.5	2	4.8	5.5
M3	2.6	5.5	6.2
M4	3.1	7	8
M5	4	8.8	10
M6	5	10	11.5
M8	6.9	12.8	14.7
M10	9	16.6	19.2
M12	10.6	17.9	20.7
M14	12.6	20.9	24.2
M16	14.6	23.9	27.5
M18	16.6	25.9	30
M20	18.6	28.9	33.3

Sucatec Part Numbers

Part Number	Size	Colour	Pack Qty
N1000200B	M2	Black	1000
N1000250B	M2.5	Black	1000
N1000300B	M3	Black	1000
N1000400B	M4	Black	1000
N1000500B	M5	Black	1000
N1000600B	M6	Black	1000
N1000800B	M8	Black	1000
N1001000B	M10	Black	500
N1001200B	M12	Black	100
N1001400B	M14	Black	100
N1001600B	M16	Black	100
N1001800B	M18	Black	100
N1002000B	M20	Black	100
N1000200W	M2	White	1000
N1000250W	M2.5	White	1000
N1000300W	M3	White	1000
N1000400W	M4	White	1000
N1000500W	M5	White	1000
N1000600W	M6	White	1000
N1000800W	M8	White	1000
N1001000W	M10	White	500
N1001200W	M12	White	100
N1001400W	M14	White	100
N1001600W	M16	White	100
N1001800W	M18	White	100
N1002000W	M20	White	100

IMPORTANT: This data sheet and its contents (the “Information”) are owned by Sucatec or are licensed to it. The Information is provided solely for informational purposes related to the products described. No license is granted for any other use, and no intellectual property rights are transferred. The Information is subject to change without notice and supersedes all previous data sheets. While believed to be accurate, Sucatec assumes no responsibility for the accuracy or completeness of the Information, any errors or omissions, or any reliance on it. Users should verify the Information and the suitability of the products for their purposes independently. Liability for any loss or damage resulting from reliance on the Information or its use (including liability due to negligence or if Sucatec was aware of potential loss or damage) is excluded. © 2025 Sucatec

Document No.: DS-N1000-NYLNUT

Revision: 01

Date of Issue: 01 November 2025

This is a controlled document. Uncontrolled if printed or stored outside of the official Sucatec document system.
