MSDS – Nylon Socket Cap Screws
Sucatec Technical Datasheet Banner

Nylon Socket Cap Screws

Nylon Socket Cap Screw – Illustration Nylon Socket Cap Screws – Product Image

Description

Sucatec Nylon Socket Cap Screws are manufactured from high-grade Nylon 66, providing a strong, lightweight and non-corrosive fastening solution. They are ideal where electrical insulation, chemical resistance and reduced weight are required, such as in electronics, cleanroom equipment, laboratory devices and general industrial assemblies.

Features

  • Material: Nylon 66
  • Lightweight, non-magnetic and corrosion-resistant
  • Excellent electrical insulation properties
  • Good resistance to many oils, greases and chemicals
  • Typical operating temperature range: -35°C to +85°C
  • Available in white and black as standard
  • Metric threads from M4 to M10 with a wide range of lengths

Technical Dimensions

All dimensions are in millimetres (mm).

Thread Size A (mm) B (mm) C (mm) D (mm) Available Lengths L (mm)
M4 5.0 4.0 6.9 3.1 5, 6, 8, 10, 12, 15, 20, 25, 30, 35, 40
M5 6.0 5.1 7.9 4.1 6, 8, 10, 12, 15, 20, 25, 30, 35, 40, 45, 50, 60
M6 8.0 6.0 9.4 5.3 8, 10, 12, 15, 20, 25, 30, 35, 40, 45, 50, 60
M8 8.0 7.8 12.0 6.4 8, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60
M10 15.0 9.5 15.2 8.4 15, 20, 25, 30, 35, 40, 45, 50, 60

Sucatec Part Number Reference

The following table lists standard Sucatec part numbers for Nylon Socket Cap Screws, available in white and black. Please contact Sucatec for additional sizes, colours or customised specifications.

Sucatec Part Number Size Colour
N107040005WM4 x 5White
N107040005BM4 x 5Black
N107040006WM4 x 6White
N107040006BM4 x 6Black
N107040008WM4 x 8White
N107040008BM4 x 8Black
N107040010WM4 x 10White
N107040010BM4 x 10Black
N107040012WM4 x 12White
N107040012BM4 x 12Black
N107040015WM4 x 15White
N107040015BM4 x 15Black
N107040020WM4 x 20White
N107040020BM4 x 20Black
N107040025WM4 x 25White
N107040025BM4 x 25Black
N107040030WM4 x 30White
N107040030BM4 x 30Black
N107040035WM4 x 35White
N107040035BM4 x 35Black
N107040040WM4 x 40White
N107040040BM4 x 40Black
N107050006WM5 x 6White
N107050006BM5 x 6Black
N107050008WM5 x 8White
N107050008BM5 x 8Black
N107050010WM5 x 10White
N107050010BM5 x 10Black
N107050012WM5 x 12White
N107050012BM5 x 12Black
N107050015WM5 x 15White
N107050015BM5 x 15Black
N107050020WM5 x 20White
N107050020BM5 x 20Black
N107050025WM5 x 25White
N107050025BM5 x 25Black
N107050030WM5 x 30White
N107050030BM5 x 30Black
N107050035WM5 x 35White
N107050035BM5 x 35Black
N107050040WM5 x 40White
N107050040BM5 x 40Black
N107050045WM5 x 45White
N107050045BM5 x 45Black
N107050050WM5 x 50White
N107050050BM5 x 50Black
N107050060WM5 x 60White
N107050060BM5 x 60Black
N107060008WM6 x 8White
N107060008BM6 x 8Black
N107060010WM6 x 10White
N107060010BM6 x 10Black
N107060012WM6 x 12White
N107060012BM6 x 12Black
N107060015WM6 x 15White
N107060015BM6 x 15Black
N107060020WM6 x 20White
N107060020BM6 x 20Black
N107060025WM6 x 25White
N107060025BM6 x 25Black
N107060030WM6 x 30White
N107060030BM6 x 30Black
N107060035WM6 x 35White
N107060035BM6 x 35Black
N107060040WM6 x 40White
N107060040BM6 x 40Black
N107060045WM6 x 45White
N107060045BM6 x 45Black
N107060050WM6 x 50White
N107060050BM6 x 50Black
N107060055WM6 x 55White
N107060055BM6 x 55Black
N107060060WM6 x 60White
N107060060BM6 x 60Black
N107080008WM8 x 8White
N107080008BM8 x 8Black
N107080010WM8 x 10White
N107080010BM8 x 10Black
N107080015WM8 x 15White
N107080015BM8 x 15Black
N107080020WM8 x 20White
N107080020BM8 x 20Black
N107080025WM8 x 25White
N107080025BM8 x 25Black
N107080030WM8 x 30White
N107080030BM8 x 30Black
N107080035WM8 x 35White
N107080035BM8 x 35Black
N107080040WM8 x 40White
N107080040BM8 x 40Black
N107080045WM8 x 45White
N107080045BM8 x 45Black
N107080050WM8 x 50White
N107080050BM8 x 50Black
N107080055WM8 x 55White
N107080055BM8 x 55Black
N107080060WM8 x 60White
N107080060BM8 x 60Black
N107100015WM10 x 15White
N107100015BM10 x 15Black
N107100020WM10 x 20White
N107100020BM10 x 20Black
N107100030WM10 x 30White
N107100030BM10 x 30Black
N107100035WM10 x 35White
N107100035BM10 x 35Black
N107100040WM10 x 40White
N107100040BM10 x 40Black
N107100045WM10 x 45White
N107100045BM10 x 45Black
N107100050WM10 x 50White
N107100050BM10 x 50Black
N107100055WM10 x 55White
N107100055BM10 x 55Black
N107100060WM10 x 60White
N107100060BM10 x 60Black
IMPORTANT: This data sheet and its contents (the “Information”) are owned by Sucatec or are licensed to it. The Information is provided solely for informational purposes related to the products described. No license is granted for any other use, and no intellectual property rights are transferred. The Information is subject to change without notice and supersedes all previous data sheets. While believed to be accurate, Sucatec assumes no responsibility for the accuracy or completeness of the Information, any errors or omissions, or any reliance on it. Users should verify the Information and the suitability of the products for their purposes independently. Liability for any loss or damage resulting from reliance on the Information or its use (including liability due to negligence or if Sucatec was aware of potential loss or damage) is excluded. © 2025 Sucatec.
Document No.: DS-N107-00000 Revision: 01 Date of Issue: 04 November 2025
This is a controlled document. Uncontrolled if printed or stored outside of the official Sucatec document system.
